This is a refurbished Thermo LTQ Orbitrap XL with LTQ XL Mass Spectrometer.
The Thermo Scientific LTQ Orbitrap XL with LTQ XL Mass Spectrometer is a high-resolution hybrid mass spectrometry system designed for advanced proteomics, metabolomics, and complex biomolecular analysis. Combining the fast ion trapping capabilities of the LTQ XL linear ion trap with the ultra-high mass accuracy and resolving power of Orbitrap technology, this system delivers exceptional sensitivity and precise mass measurements for confident compound identification and structural characterization. Ideal for research, pharmaceutical, and academic laboratories, the LTQ Orbitrap XL supports a wide range of applications including protein identification, post-translational modification analysis, and small molecule profiling.
Specifications:
- Resolution (apodized)
- 60000 (FWHM) @ m/z 400 with a scan repetition rate of 1 second
- Minimum resolution 7500@ m/z 400
- Maximum resolution 100000 @ m/z 400
- Cycle Time
- 1 scan at 60000 resolution @ m/z 400 per second
- Mass Range
- m/z 50–2000
- m/z 200–4000
- Mass Accuracy
- <3 ppm RMS for 2 h period with external calibration using defined conditions
- <2 ppm RMS with internal calibration
- Dynamic Range
- >10000 between mass spectra,
- >4000 between highest and lowest detectable mass in one spectrum
- MS/MS
- MS/MS and MSn scan functions
